JC Drawing Ver2.0.240402 Update:
1. Optimize the function of signal chain;
2. Optimize the display function of the middle layer line alignment and copper cladding, highlighted line alignment and copper cladding are only displayed on the click interface;
3. The via hole no longer supports to pass through(easily mixed up with the overlapping pad);
4. Fix the problems that some of the middle layer alignment lines are not displayed;
5. The technical support QR code will not be displayed by default, click the Contact Tech Support button if necessary.
6. Modify the problems that the faulty notes of signal chain cannot be queried;
7. When opening JC drawing, the signal chain function page will be displayed by default (the schematic function page was displayed by default previously);
8. The middle layer line alignment is closed by default, and the last state will be saved automatically when opening or closing;
9. Improve other known issues and optimize part of the helpful prompts.
